The flicker was the radar
I built a small desk instrument on an ESP32 — a screen that shows power draw and a few other live readings, with a menu you click through using the boot button. A presence radar wakes the display when I sit down and dims it when I leave.
It worked. Then every screen started flickering, several times a second, and it got worse the moment I scrolled the menu.
The wrong instinct, which I had first
Flicker on an embedded display looks like a rendering problem. That is the whole point of the symptom: it is visibly about drawing, so you go and read the drawing code.
I looked at partial redraws. I looked at whether the menu was clearing and repainting the full frame instead of just the changed row. I looked at the refresh rate. All plausible, all wrong, and I found nothing because there was nothing there to find.
The thing that broke it open was not looking harder at the renderer. It was asking a different question:
“is it because of the radar? running in background? if so please optimise so that UI interrupts don’t happen — list down all the tasks running, the ones in background all the time, and the ones on periodic intervals.”
Listing every periodic task is a dull, mechanical question. It is also the one that found it, because the flicker was never in the drawing code. It was in when the drawing code got interrupted.
What was actually happening
The radar sensor polls. The display draws. Neither knows about the other, and on a microcontroller with no preemptive isolation between them, a poll that lands mid-frame leaves you looking at a half-drawn screen for a few milliseconds.
Do that a few times a second and you get flicker. Scroll the menu — which drives the redraw rate up, and so multiplies the number of chances to collide — and it gets dramatically worse. That last detail was the confirmation. The bug got worse in proportion to how often I drew, which points at a collision, not at bad drawing.
This is the same shape as the two heartbeats that killed my WebSocket, which I ran into a couple of days later on a different device. Two periodic things, each individually correct, each unaware of the other, interfering on a schedule. The symptom appears in whichever component is more visible — the socket, or the screen — and the cause is in the timing relationship between them, which lives in neither.
I now treat “it’s periodic and it got worse when I did more of X” as a strong signal to stop reading the component that hurts and go enumerate the clocks.
The fix, and the better fix
The immediate fix is to stop the two from overlapping: make the sensor read cheap and predictable, and keep it away from the window where a frame is being pushed out.
The structural fix is the one I actually wanted, and it is the same answer as on every other display I have built since — draw the whole frame into a buffer, then push the buffer. If the panel only ever receives complete frames, an interruption during composition costs you a little latency instead of a visible tear. It cannot flicker, because a partial frame never reaches the glass.
That costs memory, which on an ESP32 is the resource you are always short of. It is worth it. Nearly every display problem I have had since has been solved or prevented by that one decision.
The bit worth keeping
Two things I would tell myself before starting.
The component where a bug appears is not usually the component that causes it. A flickering screen is evidence about drawing only in the sense that drawing is the thing being interrupted. The question “what else runs on a timer” is nearly free to ask and I asked it far too late.
When you are stuck, enumerate instead of investigating. Not why is this flickering, which invites a theory — but what are all the periodic tasks, background and interval. Boring, exhaustive, and it turns a hunt into a list you can read. Half the hard bugs I have found in firmware came from writing down everything in a category rather than reasoning about the one thing I suspected.
The radar was doing its job perfectly. That was the problem.
